High Speed Motor Test Bench ( Low Power )
High Speed Motor Test Bench ( Low Power )
Technical Advantages
-Torque measurement control accuracy：±0.05%FS/±0.1%FS.
-Speed sensor pulse resolution: max 2048ppr.
-Torque control accuracy：±0.5%FS~±1%FS.
-Steady state speed control accuracy：±1rpm（≤10000rpm），±0.1%FS（＞10000rpm）.
-DAQ sampling rate：1kHz.
-User data acquisition system channel: optional.
-Temperature sensor measuring range：-50℃~200℃.
Product Spectrum
The Atestman Dynamometer Electric Motor Test Stand (or Electric Motor Test Bench) provides maximum reliability, excellent durability and flawless performance. It is composed of dynamometer, motor inverter, testbench mechanics, battery simulator, connection box, cooling system, power analyzer, data acquisition system, automation control and measurement system, etc. with our unique shaft centering technology to achieve your precise testing requirements.
